Purelux Terrain Curve 120W - Curved / 36 cm

The elegant 36 cm long curved work light provides an exceptionally wide and even light pattern. Perfectly suited for installation on smaller work machines, excavators, and off-road vehicles.

Main Features:

• Curved Design: Offers a wider light pattern compared to straight panels, naturally directing light to the sides as well.
• Luminous Flux: Theoretical 10,080 lm (measured at 101 W power).
• Beam Range: 144 m (@ 1 lux) / 289 m (@ 0.25 lux).
• Color Temperature: 5700K – neutral light reduces eye fatigue and ensures clear visibility even during prolonged use.
• IP67 Protection Class: Dust and waterproof, withstands extreme weather conditions.
• Scratch-Resistant Lens: Flat, UV-protected polycarbonate lens reduces accumulation of snow, ice, and dirt.
• Corrosion-Resistant Aluminum Frame: Powder-coated UV-protected surface ensures long-lasting durability.
• Stylish Dark Design: Perfectly suits both modern work machines and vehicles.
• Easy Installation: Includes side mounts and adjustable rail mounts.
• Radio Interference Protection: Complies with ECE R10 standard.
• Operating Voltage Range (10–30V): Suitable for both 12V and 24V systems.
• Warranty: 24 months.

Technical Specifications:

• Power Supply Voltage: 10–30 V (DC)
• Current Consumption: 4.2A @ 24V
• Measured Power: 101 W
• Luminous Flux: Theoretical 10,080 lm
• Beam Range: 144 m (@ 1 lux) / 289 m (@ 0.25 lux)
• Color Temperature: 5700K (measured 5662K)
• Protection Class: IP67
• Radio Interference Protection: ECE R10
• Mounting: Side mounts, adjustable rail mounts
• Connector: Deutsch DT-2
• Cable Length: 50 cm
• Dimensions: 356 x 70 x 67 mm (Width x Height x Depth)
• Weight: 1400 g
• Warranty: 24 months

Included in the Package:

• 1 x Purelux Terrain Curve 120W work light
• 2 x Side mounts
• 2 x Adjustable rail mounts
• Mounting bolts
• Installation and connection manual (EN/FI/SE/NO/DK)

Applications:

• Small Work Machines: Effective lighting in tight and hard-to-reach areas.
• Excavators and Tractors: Wide beam ensures even visibility in the work area.
• Off-Road Vehicles (ATV, UTV): Compact design allows installation in narrow spaces.
• Construction Machines: Durable construction and weather resistance withstand harsh working conditions.

👉 Purelux Terrain Curve 120W – Compact and Powerful Work Light That Provides Wide and Even Illumination in the Most Demanding Conditions!
