Purelux Rotatable 90, 90W / Wide

360° rotatable work light mount that provides an exceptionally wide beam, excellent power, and durability even in the most demanding conditions.

Main Features:

• 360° Rotatable Mount: Allows directing the light exactly where it is needed most.
• Luminous Flux: Measured 6367 lm (manufacturer: 7650 lm).
• Beam Range: 88 m (@ 1 lux) / 176 m (@ 0.25 lux).
• Color Temperature: 5000K – neutral light that reduces eye fatigue even during prolonged work.
• Wide Light Pattern: Balanced and uniform light without dark spots.
• IP68 Protection Class: Dust and waterproof, withstands even the harshest conditions.
• CISPR25 Class 4: High-level radio interference protection.
• Materials: Strong aluminum frame, virtually unbreakable polycarbonate lens, stainless steel mounting bracket.
• Durable Finish: Powder-coated housing offers UV and corrosion protection.
• Operating Voltage Range: 9–32V – suitable for both 12V and 24V systems.
• Warranty: 24 months.

Technical Specifications:

• Operating Voltage: 9–32 V (DC)
• Current Consumption: 1.91A @ 24V
• Measured Power: 62 W
• Luminous Flux: 6367 lm (manufacturer: 7650 lm)
• Beam Range: 88 m (@ 1 lux) / 176 m (@ 0.25 lux)
• Color Temperature: 5000K (measured: 5096K)
• Protection Class: IP68
• Radio Interference Protection: ECE R10, CISPR25 Class 4
• Operating Temperature: -45°C to +85°C
• Mounting: Rotatable mounting bracket
• Connector: DT-2
• Cable Length: 50 cm
• Dimensions: 127 x 127 x 80 mm (Width x Height x Depth)
• Height with bracket: 158 mm
• Weight: 1550 g
• Warranty: 24 months

Included in the Package:

• 1 x Purelux Rotatable 90 Gen2 work light
• 1 x Rotatable mounting bracket
• 1 x Mounting bolt and nut (M8, 50 mm)
• 1 x Mounting bolt and nut (M10, 25 mm)
• 1 x Connector counterpart
• Installation and connection manual (EN/FI/SE/NO/DK)

Applications:

• Heavy Machinery: Excavators, tractors, loaders.
• Off-road Vehicles (ATV, UTV): Compact design allows installation in tight spaces.
• Vans and Trucks: Wide and uniform light pattern for illuminating the work area.
• Construction Machines: Durable and reliable even in extreme conditions.

👉 Purelux Rotatable 90 Gen2 – Flexible and Reliable Light That Meets the Most Demanding Lighting Needs!
