Purelux Panther Alpha 20 / 20W / Backlight

Exceptionally stylish and durable work light that combines a wide light pattern, two-color parking light, and excellent performance even in the most demanding conditions.

Main Features:

• Luminous Flux: Measured 1394 lm.
• Beam Range: 56 m (@ 1 lux).
• Beam Type: Wide and uniform light pattern – ideal for illuminating the immediate surroundings.
• Light Color Temperature: 5000K – neutral light reduces eye fatigue and ensures excellent visibility.
• Compact Design: Only 96 x 45 x 50 mm – suitable for installation in tight spaces.
• Frameless Design: The lens is mounted flush with the frame, preventing accumulation of snow, ice, and dirt.
• Quality Materials: Durable aluminum housing and virtually unbreakable polycarbonate lens.
• Operating Voltage Range: 9–36V – suitable for both 12V and 24V systems.
• IP69K Protection Class: Fully dust and waterproof.
• Radio Interference Protection: ECE R10 standard.
• Warranty: 36 months.

Technical Data:

• Operating Voltage: 9–36 V (DC)
• Current Consumption: 0.80A @ 24V (work light), 0.225A @ 24V (parking light)
• Nominal Power: 20 W (work light), 5.4 W (parking light)
• Luminous Flux: 1500 lm (manufacturer), 1394 lm (measured)
• Beam Range: 56 m (@ 1 lux)
• Color Temperature: 5000K
• LEDs: Osram LEDs
• Protection Class: IP69K
• Operating Temperature: -40°C to +60°C
• Cable Length: 50 cm with DT-4 connector
• Dimensions: 96 x 45 x 50 mm (Width x Height x Depth)
• Height with Mounting: 71 mm
• Weight: 320 g
• Certifications: EMC, ECE R10, R23, R149, CE, RoHS
• Warranty: 36 months

Included in the Package:

• 1 x Purelux Panther Alpha 20 work light
• 1 x Sturdy mounting bracket
• 1 x Mounting bolt
• 1 x Power cable with DT-4 connector
• 1 x Connector counterpart
• Installation and connection manual (EN/FI/SE/NO/DK)

Applications:

• Work Machines and Heavy Equipment: Excavators, tractors, forklifts.
• Vans and Trucks: For illuminating the surrounding area and work zone.
• Off-road Vehicles (ATV, UTV): Additional lighting in challenging conditions.
• Construction Machinery: Lighting at construction sites and workplaces.
• Specific Applications: Perfect for locations requiring a compact yet powerful light.
