Purelux Panther Aero S540 Gen2 - Surge / 54 cm / 108W / Ref. 25

Ultra-thin and aerodynamic auxiliary light offering two power modes, a wide combination light beam, and dual-tone parking lights. The perfect choice for modern vehicles!

Features:

• Two power modes: Road traffic suitable mode and Purelux PowerBoost® maximum performance.
• Light output: 8151 lm (PowerBoost®) / 3241 lm (road traffic mode).
• Light beam: 479 m @ 1 lux (PowerBoost®).
• Optimal color temperature: 5000K ensures clear and natural light.
• Aerodynamic design: Low profile and stylish black appearance.
• Dual-tone parking light: White and orange light.
• Frameless Lexan lens: Weather- and impact-resistant, does not accumulate ice or dirt.
• Easy installation: Top and adjustable bottom mounting brackets.
• Memory function: The light remembers the last used mode.
• Radio frequency interference protection: Complies with ECE R10 standard.

Technical specifications:

• Operating voltage: 9–36 V (DC)
• Power: 108 W (nominal power)
• Current consumption:
  • PowerBoost®: 10.41A @ 12V / 4.12A @ 24V
  • Road traffic mode: 2.91A @ 12V / 1.29A @ 24V
• Luminous flux:
  • PowerBoost®: 8151 lm (measured)
  • Road traffic mode: 3241 lm (measured)
• Light beam:
  • PowerBoost®: 479 m @ 1 lux / 958 m @ 0.25 lux
  • Road traffic mode: 303 m @ 1 lux / 606 m @ 0.25 lux
• Color temperature: 5000K (measured 5050K)
• Protection class: IP68 / IP69K
• Connection: Deutsch DT-2 plug
• Cable length: 50 cm
• Dimensions: 540 x 42 x 62.5 mm (Width x Height x Depth)
• Height with side mounts: 57 mm
• Height with bottom mounting brackets: 62 mm
• Weight: 1500 g
• Certifications: CE, ECE R10, R148, R149 (PowerBoost® mode is not permitted for road traffic)
• Warranty: 24 months

Included in the package:

• 1 x Purelux Panther Aero S540 auxiliary light
• 2 x Width adjustable bottom mounting brackets
• 2 x Top mounting brackets
• 1 x Power cable with DT-2 plug
• 1 x Installation manual (EN, SE, NO, DK, FI)

Light beam characteristics:

• Curved design: Maximizes beam width, ideal for low mounting positions.
• Straight design: Wider light area on the sides, perfect for illuminating broader areas.
• Neutral color temperature (5000K): Reduces eye fatigue and ensures clear visibility in all conditions.

Installation instructions:

1. Power connection: Connect the DT-2 plug to the auxiliary light.
2. Parking light: Yellow wire for orange parking light, white wire for white parking light.
3. Mode switching: Use the integrated button to switch modes.
4. Mounting: Use adjustable brackets to optimize installation.

👉 The Purelux Panther Aero S540 Gen2 combines stylish design, exceptional light output, and reliability – the ideal auxiliary light for modern vehicles!
